ep76m 2Master Bond EP76M is a two component, nickel filled epoxy adhesive that features outstanding electrical conductivity with a volume resistivity of 5-10 ohm-cm. This system is formulated to cure at room temperature or more rapidly at elevated temperatures and is well suited for high performance bonding, sealing, and coating applications.

Unlike the majority of two part nickel conductive systems, EP76M has a one-to-one mix ratio by weight or volume. The high strength bonds are remarkably adaptable to thermal cycling and resistant to chemicals including water, oil and most organic solvents. Adhesion to metals, glass, ceramics, vulcanized rubbers and many plastics is excellent.

It readily develops a high tensile shear strength of more than 2,000 psi when measured and cured at 75°F.  It is 100% reactive and does not contain any diluents or solvents. EP76M has an exceptionally wide temperature range of -60°F to +250°F.

Get more details on EP76M.

Electrically Conductive Adhesives

Master Bond offers a wide range of electrically conductive adhesive systems including:
  • Graphite filled
  • Nickel filled
  • Silver coated/nickel filled
  • Silver filled
Learn more about the advantages of Master Bond epoxies with excellent electrical conductivity.

On the other hand, if you're looking for information on electrically insulative products, we feature technical tips with helpful hints on:
