The following products have been recently tested by an independent laboratory based on the requirements within the Telcordia GR-1221 specification for damp heat storage testing, i.e. 1,000 hours of exposure to 85°C and 85% relative humidity. A full list of Master Bond's 85°C/85% tested systems is available here.
|
|
EP113: Optically Clear, Nanosilica Filled Epoxy |
Formulated for potting, coating and sealing applications, EP113 is a two component, nanosilica filled epoxy. The nano particles enhance the dimensional stability and the already exceptionally low shrinkage upon curing. This low viscosity system bonds well to a wide variety of substrates including metals, composites, glass, ceramics and plastics. As a toughened compound, it has good resistance to thermal cycling and shock over the wide temperature range of -100°F to +450°F [-73°C to +232°C]. Additionally, this compound is a top tier electrical insulator.
For more information, request a technical data sheet on EP113
|
|
EP30-3LO: Versatile, Optically Clear Two Part Epoxy System
|
With a glass transition temperature exceeding 175°C, EP30-3LO combines superior chemical resistance along with passing NASA low outgassing testing requirements. It has a non-critical 100 to 30 mix ratio by weight, and while it requires heat curing, it offers a long open time of 6-10 hours for a 100 gram batch. This product bonds well to a wide variety of substrates including metals, glass, composites and many plastics and rubbers. Electrical insulation properties are outstanding.
For more information, request a technical data sheet on EP30-3LO
|
|
Supreme 12AOHT-LO: NASA Low Outgassing Approved, One Part System |
Supreme 12AOHT-LO is a toughened system with superior resistance to aggressive thermal cycling and shock. Cryogenically serviceable, it combines superior thermal conductivity with reliable electrical insulation properties. This dimensionally stable epoxy has formidable bond strength, particularly in the shear mode, ranging from 3,400-3,600 psi. Its service temperature range extends from 4K to +500°F [4K to +260°C].
For more information, request a technical data sheet on Supreme 12AOHT-LO
|
|
Supreme 45HTND-2LO Black: Toughened, High Temperature Resistant Epoxy |
Supreme 45HTND-2LO Black is a two component system for structural bonding applications. It features high shear and peel strengths of 2,200-2,400 psi and 10-15 pli, respectively. As a toughened epoxy Supreme 45HTND-2LO Black is primarily formulated to withstand rigorous thermal cycling, especially when bonding dissimilar substrates. It has a non-drip, paste consistency and is serviceable over the wide temperature range of -100°F to +450°F [-73°C to +232°C].
For more information, request a technical data sheet on Supreme 45HTND-2LO Black
|
|
MasterSil 151Med: Silicone Compound for Medical Applications |
MasterSil 151Med is an optically clear, flexible, tough, high performance potting and encapsulation compound with a long working life after mixing. It exhibits superior electrical insulation properties and very low shrinkage upon cure. MasterSil 151Med is resistant to vibration/shock and has a service operating temperature range of -65°F to +400°F [-54°C to +204°C]. It meets USP Class VI requirements for medical device applications.
For more information, request a technical data sheet on MasterSil 151Med
|
|
|
|
