One component, nanosilica filled, dual cure system with UV and heat curing mechanisms
- Thixotropic paste
- Minimal shrinkage upon curing
- Low coefficient of expansion
- Cures in shadowed out areas at 80°C
Master Bond UV22DC80ND is a nanosilica filled, UV dual cure system. The secondary cure is accomplished by adding heat, with the minimum temperature being 80°C. Essentially, this epoxy based system will cure readily upon exposure to UV light and if there are any shadowed out areas, heating at 80°C will complete the cure. The 80°C curing feature is particularly useful given the sensitivity of many plastics to elevated temperatures.
The consistency of UV22DC80ND can best be described as a thixotropic paste. It dispenses readily, but has limited flow. This UV is a cationic type cure and is not oxygen inhibited. It bonds well to a wide variety of substrates including metals, glass, ceramics and most plastics. UV22DC80ND has very good chemical resistance to many acids, bases, fuels and solvents. It is a superb electrical insulator and it is also able to withstand rigorous thermal cycling. The service temperature range is -60°F to +350°F. As a nanosilica filled system, it has exceptionally low shrinkage upon curing and stellar dimensionally stability.
Typically the UV portion occurs in 10-30 seconds at 365 nm with 10-40 milliwatts/cm2 of output. Areas not cured because of shadowing effects can be readily cured at 80°C for 30-60 minutes. Post curing at 125-150°C for 15-30 minutes will increase the Tg. Significantly, in addition to bonding, this UV can be used for small encapsulations as it will cure in thickness up to 0.09 inches. The combination of special flow properties and dual curing is especially intriguing. This epoxy is a viable option for high tech aerospace, electronics, optical and specialty OEM applications.
- One component system; no mixing needed
- Dual curing mechanism allows for curing in shadowed out areas and rapid fixturing time at 80°C
- No oxygen inhibition
- Very low shrinkage upon curing
- Nano filled, high dimensional stability
- NASA low outgassing
UV22DC80ND is available is various sizes and units to accommodate customer's needs.
