Two component epoxy compound for bonding, coating and sealing
- Thermally conductive, electrically insulative
- Room temperature curing
- Toughened system, withstands thermal cycling
- Excellent physical strength properties
Master Bond Supreme 11ANHT is a two component thermally conductive, electrically insulating epoxy resin system for bonding, coating and sealing. It has a forgiving one to one mix ratio by weight or volume. It is formulated to cure at room temperature or more rapidly at elevated temperatures with the optimum being 8-12 hours at room temperature followed by 1-2 hours at 150-200°F. It is relatively fast setting and a 100 gram mass has an open time of about 20-30 minutes.
It bonds well to a wide variety of substrates including metals, composites, ceramics, glass and many plastics. It is a toughened system and is capable of withstanding rigorous thermal cycling and is well suited for bonding dissimilar substrates. Most important, Supreme 11ANHT has higher thermal conductivity without sacrificing electrical insulation. It has exceptionally good adhesion in both shear and peel modes. The color of both Part A and Part B is off white. The service temperature range is -112°F to +400°F. This epoxy is a solid choice in electronic, optical, aerospace and specialty OEM applications, where superior heat transfer is advantageous.
- Convenient handling
- Versatile cure schedules
- Toughened system; withstands thermal cycling
- Exceptionally strong adhesive
- Very good dimensional stability
- High thermal conductivity and electrical insulation
- Temperature range up to +400°F
Supreme 11ANHT is available is various sizes and units to accommodate customer's needs.
