Two component, room temperature curing epoxy polysulfide system

Key Features

  • One to one mix ratio
  • Flexible bonds
  • Withstands thermal cycling
  • Exceptional chemical resistance to fuels and oils
  • Excellent electrical insulation properties
  • Fully complies with RoHS regulations


Note: EP21TPLV-NV complies with RoHS3 Directive (EU) 2015/863. It is a new version of EP21TPLV, which has been discontinued.

Product Description

Master Bond EP21TPLV-NV is a two component epoxy polysulfide system formulated to cure at room temperature or more rapidly at elevated temperatures, with a one to one mix ratio by weight or volume. It’s a versatile material that can be used as an adhesive, coating, encapsulant and especially as a sealant. It resists a wide array of chemicals including water, gasoline, fuels, oils, hydrocarbons, hydraulic fluids and many acids and bases. Significantly, unlike many chemical resistant epoxy based materials, this system has excellent toughness. These properties enable EP21TPLV-NV to withstand rigorous thermal cycling as well as mechanical and thermal shocks. It bonds well to a variety of substrates, including metals, glass, ceramics and many rubber and plastic materials. The cured system has excellent electrical insulation properties. Its service temperature range is -80°F to +250°F. One unusual feature of EP21TPLV-NV is the influence of adding heat to the curing cycle. When cured at room temperature the Shore D hardness is 60-65; when cured at 200°F for 2-3 hours, its hardness is 15-20 Shore D. Therefore, to obtain the optimum properties, EP21TPLVNV should be cured at room temperature. The color of Part A is tan and Part B is amber, although, other colors are available. Polysulfide systems, such as EP21TPLV-NV, have been used as fuel tank sealants and coatings, as well as for potting electrical connectors and other components exposed to fuels, oils and lubricants. EP21TPLV-NV can be used in aerospace, OEM, electronic, electrical, chemical and related industries where room temperature curing, toughness and resistance to fuels, lubricants and similar type chemicals are needed.

Product Advantages

  • Convenient mixing: forgiving one to one mix ratio by weight or volume
  • Easy to apply — adhesive spreads evenly and smoothly
  • Ambient temperature curing imparts optimal chemical resistance and hardness
  • Produces tough bonds; resistant to thermal cycling
  • Good hardness and elongation
  • Superb resistance to oils, fuels and related chemicals

Industrial Certifications


Meets EU Directive 2015/863

Packaging


Cans

Double Barrel Cartridge

FlexiPak®

Gun Applicator

Syringes

EP21TPLV-NV is available is various sizes and units to accommodate customer's needs.
